Purpose
Charging electric vehicle batteries
Application
Public, outdoor (installed in parking lots, parking lots, etc.)
Charging type
AC Mode 3, Mode 1
Input voltage
3 phase, 400V, 32A
Maximum output power, kW
22; , 3,6
Station access
RFID card, SMS, Mobile app
Safety
Residual current device (RCD), before connecting the sockets are de-energized.
Degree of protection
IP54
Output voltage
3 phase, 400V, 32A, 1 phase, 230V, 16A
Status indication
LED tricolor
Electricity meter
Available
Weight, kg
22
Dimensions (WxDxH), mm
224х224х1170
Electric charging stations
Purpose
Charging electric vehicles
Application
Public, outdoor (installed in parking lots, parking lots, etc.)
Charging type
Mode 4
Input voltage
400 V ± 10%, 3 phases, 85 A, 50 Hz ± 10%
Station access
RFID card (13.56 MHz), NFC card, Mobile app
Safety
Differential switch, Connectors are de-energized when plugged in, Surge protection, Control voltages 12 V, 24 V
Degree of protection
IP54
Output voltage
from 200 to 1000 V, 125 A
Status indication
tricolor, LED
Electricity meter
Electricity meters that are in the register of measuring instruments of the Republic of Belarus., DC output counter
Dimensions (WxDxH), mm
660*560*1851
Rated output power, kW
50
Electric charging stations
Purpose
Charging electric vehicle batteries
Application
Public, outdoor (installed in parking lots, parking lots, etc.)
Charging type
AC Mode 3
Input voltage
3 phase, 400V, 32A
Maximum output power, kW
22
Station access
Auto power on when connected to an electric vehicle
Safety
Residual current device (RCD), before connection, the socket is de-energized
Degree of protection
IP54
Output voltage
3 phase, 400V, 32A
Status indication
LED tricolor
Electricity meter
No
Weight, kg
22
Dimensions (WxDxH), mm
224х224х1170
Electric charging stations
Purpose
Charging electric vehicle batteries
Application
Public, outdoor (installed in parking lots, parking lots, etc.)
Charging type
AC Mode 3
Input voltage
3 phase, 400V, 32A
Maximum output power, kW
22
Station access
RFID card, SMS, Mobile app
Safety
Residual current device (RCD), before connection, the socket is de-energized., Without lightning protection (SPD).
Degree of protection
IP54
Output voltage
3 phase, 400V, 32A
Status indication
LED tricolor
Electricity meter
available
Weight, kg
22
Dimensions (WxDxH), mm
224х224х1170
Electric charging stations
Purpose
Charging electric vehicle batteries
Application
Public, outdoor (installed in parking lots, parking lots, etc.)
Charging type
AC current (Mode 3)
Input voltage
1 phase, 230V, 32A
Maximum output power, kW
7,2
Station access
RFID card, SMS, Mobile app
Safety
Residual current device (RCD), the cable is de-energized before connection.
Degree of protection
IP54
Output voltage
1 phase, 230V, 32A
Status indication
LED tricolor
Electricity meter
Available
Weight, kg
23
Dimensions (WxDxH), mm
327х165х1002
Integrated cable
Built-in cable Type 1 connector (J1772, USA)
Electric charging stations
Purpose
Charging electric vehicles
Application
Public, outdoor (installed in parking lots, parking lots, etc.)
Charging type
Mode 4
Input voltage
400 V ± 10%, 3 phases, 140 A
Maximum output power, kW
500 V, 125 A
Safety
RCD, when connected, the connectors are de-energized, surge protection
Degree of protection
IP54
Status indication
tricolor LED
Electricity meter
Electricity meters that are in the register of measuring instruments of the Republic of Belarus.
Rated output power, kW
50
Electric charging stations
